Intelli - i Max
Double conversion True On Line UPS
with Inbuilt Galvanic Isolation Transformer
- Three phase – In
- Three phase – Out
- 10KVA – 30KVA
Maruthi intelli-i max series On Line UPS which provides 3Phase output to load with inbuilt Isolation Transformer act as an interface between the mains and the loads, this On Line UPS guarantees the continuity and quality of electrical power supplied to the loads, irrespective of the power condition at the input. Maruthi intelli - i max On Line UPS system with inbuilt isolation totally isolate the load from distortion and the line noise that a raises from the main supply. This ensures 100% protection to the load connected to the UPS from the power disturbance including harmonic and common mode noise.
Maruthi intelli -i On Line UPS system using the world best DSP technology ensures
- 100% protection to the load from all power disturbances.
- 100% safety for your sophisticated equipments.
- Preventing Data losses.
- Ensures enhanced battery life.
- High quality power output.
- Maximum availability of UPS.
Appliances
Workstations, Internet Servers / Data Centers, Network equipments, Telecom equipments, Banks, ATM machines, Printing machines, Life saving medical equipments, Textile industries, Process control, Manufacturing Industries(3phase output.
Active Power Factor Correction - 30% Power saving.
Intelligent Battery Charger
Galvanic Isolation
- Features
- Technical Specification
- Documentation
- DSP based technology.
- Pure sine wave output - Reliable and Regulated Power.
- Inbuilt Galvanic Isolation Transformer to isolate all power problems that a raises from main supply
- Active Power factor Correction(0.99) - -Power saving upto 30%.
- Intelligent Battery Management (IBT) charger - Extended Battery life
- Compliance to International standard.
- User friendly LCD display.
- Protection against abnormal input, over charging, Deep Discharging, Over Load and short circuit.
Advantage of Maruthi
- 24 x 7 world class tele support.
- 15 + years of experience in power electronics.
- On site comprehensive warranty.
- Free Preventive Maintenance at regular interval.
| Three Phase I/P Single Phase O/P | |
|---|---|
| PARAMETER | SPECIFICATION |
| INPUT | |
| Normal Voltage | 415V AC three Phase & N |
| Input Voltage Window | ( + 25% ) |
| Normal Frequency | 50 Hz + 6% |
| DC BUS | 120 - 360VDC |
| RECTIFIER | Full wave. |
| CHARGER | Active Input Power Factor Correction. |
| INPUT PF | >.99 |
| INPUT CURRENT THD. | <5% |
| Type | CVCC |
| Nominal Voltage Regulation | ( + ) 1% |
| Ripple (without battery) | < 1% |
| OUTPUT | |
| Power factor | Unity as per IEC 62040-3 (performance standards) |
| Nominal Voltage | 400VAC, 3Phase-3Phase with N, 220VAC Single phase between L & N |
| Regulation | ( + ) 1% |
| Frequency | 50Hz + 0.1 Hz |
| Waveform | True sine wave |
| ISOLATION | True Online with complete galvanic isolation as per IEC 62040-1 (saftey standards) |
| Total Harmonic Distortion | <2% Minimum for linear load, 5% for non linear load |
| Overload Capacity | 125% for 10 mins, 150% for 1Sec |
| Invertor Type | IGBT based PWM with Instantaneous Sine Wave Control |
| Transient Response | Remain within +1 % & recover to 100% within one ? cycle |
| Crest Factor | 3:1 |
| Duty | Continuous |
| Manual Bypass | Provided |
| EFFICIENCY | |
| Invertor Efficiency( DC to AC ) | >93% |
| Converter Efficiency | >94% |
| Overall Efficiency | >87% |
